Type 3R Wiring Trough C3RWT Series
Application:
Designed for use to protect multiple wiring junctions in outdoor environments against the ingress of rain, sleet, snow and the external formation of ice.
Standards:
UL870 Type 3R
CSA Type 3R
Complies with
NEMA Type 3R
IEC 60529, IP24
Construction:
Formed and spot welded from 14 or 16 gauge galvanized steel
Drip shield top design protects the enclosure against rain, snow or sleet
Embossed mounting holes on back of enclosure
Slip on removable front cover is secured with screws
Padlocking hasp
To fully comply with UL870 - 2008 requirements a bonding stud is provided on the cover and a ground stud is provided in the enclosure
A #10 AWG - 12" grounding strap with crimped on ring terminals is also provided to comply with UL requirements
Finish:
Enclosure and cover are finished in ANSI 61 gray powder coating.
Displaying 1 - 10 of 37
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
C3RWT10116
Enclosures
 RoHS Compliant
Type 3R Wiring Trough - 10x10x116 - Steel/Gray 3R TROUGH 10X10X116 (10 x 10 x 116) Hammond PN C3RWT10116 : UPC [62398… |
Hammond Mfg.
Series C3RWT |
Total Stock: 10
Drop Ship Quantity: 10
Factory Lead Time: 55
|
1 - 1$497.50 2 - 2$489.60 3 - 9$483.10 ... |
|
|
C3RWT1024
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 10x10x24 - Steel/Gray 3R TROUGH 10X10X24 (10 x 10 x 24) Hammond PN C3RWT1024 : UPC [623980847… |
Hammond Mfg.
Series C3RWT |
Total Stock: 100
Drop Ship Quantity: 100
Factory Lead Time: 55
|
1 - 1$168.10 2 - 3$165.40 4 - 9$162.80 ... |
|
|
C3RWT1036
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 10x10x36 - Steel/Gray 3R TROUGH 10X10X36 (10 x 10 x 36) Hammond PN C3RWT1036 : UPC [623980847… |
Hammond Mfg.
Series C3RWT |
Total Stock: 80
Drop Ship Quantity: 80
Factory Lead Time: 55
|
1 - 1$189.90 2 - 2$186.80 3 - 9$183.90 ... |
|
|
C3RWT1048
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 10x10x48 - Steel/Gray 3R TROUGH 10X10X48 (10 x 10 x 48) Hammond PN C3RWT1048 : UPC [623980847… |
Hammond Mfg.
Series C3RWT |
Total Stock: 20
Drop Ship Quantity: 20
Factory Lead Time: 55
|
1 - 1$213.90 2 - 2$210.40 3 - 4$207.00 ... |
|
|
C3RWT1072
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 10x10x72 - Steel/Gray 3R TROUGH 10X10X72 (10 x 10 x 72) Hammond PN C3RWT1072 : UPC [623980847… |
Hammond Mfg.
Series C3RWT |
Total Stock: 15
Drop Ship Quantity: 15
Factory Lead Time: 55
|
1 - 1$298.90 2 - 3$294.10 4 - 9$290.30 ... |
|
|
C3RWT12116
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 12x12x116 - Steel/Gray 3R TROUGH 12X12X116 (12 x 12 x 116) Hammond PN C3RWT12116 : UPC [62398… |
Hammond Mfg.
Series C3RWT |
Total Stock: 20
Drop Ship Quantity: 20
Factory Lead Time: 55
|
1 - 1$573.00 2 - 4$565.00 5 - 9$558.00 ... |
|
|
C3RWT1236
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 12x12x36 - Steel/Gray 3R TROUGH 12X12X36 (12 x 12 x 36) Hammond PN C3RWT1236 : UPC [623980847… |
Hammond Mfg.
Series C3RWT |
Total Stock: 125
Drop Ship Quantity: 125
Factory Lead Time: 55
|
1 - 1$246.40 2 - 2$242.40 3 - 4$238.50 ... |
|
|
C3RWT1296
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 12x12x96 - Steel/Gray 3R TROUGH 12X12X96 (12 x 12 x 96) Hammond PN C3RWT1296 : UPC [623980847… |
Hammond Mfg.
Series C3RWT |
Total Stock: 11
Drop Ship Quantity: 10
Factory Lead Time: 55
|
1 - 1$461.40 2 - 2$454.10 3 - 9$448.10 ... |
|
|
C3RWT418
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 4x4x18 - Steel/Gray 3R TROUGH 4X4X18 (4 x 4 x 18) Hammond PN C3RWT418 : UPC [623980847313]… |
Hammond Mfg.
Series C3RWT |
Total Stock: 75
Drop Ship Quantity: 75
Factory Lead Time: 55
|
1 - 2$39.90 3 - 4$39.20 5 - 9$38.60 ... |
|
|
C3RWT424
Enclosures
RoHS Compliant
Type 3R Wiring Trough - 4x4x24 - Steel/Gray 3R TROUGH 4X4X24 (4 x 4 x 24) Hammond PN C3RWT424 : UPC [623980847320]… |
Hammond Mfg.
Series C3RWT |
Total Stock: 92
Drop Ship Quantity: 90
Factory Lead Time: 55
|
1 - 1$48.00 2 - 3$47.20 4 - 9$46.40 ... |
