FiltersC3RSC
Type 3R Painted Galvanized Steel Junction Box C3R SC Series Lift-Off Cover with Screws and w/ Knockouts
Application:
Designed for use as a wiring/junction box.
Provides protection against rain, sleet, snow and dripping water.
Standards:
UL-50 Type 3R
CSA Type 3R
Complies with:
NEMA Type 3R
IEC 60529, IP24
Construction:
Formed and spot welded from 16 or 14 gauge galvanized steel.
Drip-shield top and seam-free sides, front and back.
Slip-on removable cover fastened with plated steel screws.
Door handles on body type C enclosures.
Embossed mounting holes on back of enclosure.
Easily removed knockouts on bottom of enclosure.
Padlocking hasp.
No Gasket.
Finish:
Enclosure and cover are finished in ANSI 61 gray powder coating.
Displaying 1 - 10 of 50
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
C3R10104SC
Enclosures
 RoHS Compliant
Type 3R Screw Cover - 10 x 10 x 4 - Steel/Gray 3R SCREW COV 10X10X4 (10 x 10 x 4) Hammond PN C3R10104SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 20
Drop Ship Quantity: 20
Factory Lead Time: 55
|
1 - 2$34.10 3 - 4$33.50 5 - 9$33.00 ... |
|
|
C3R10106SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 10 x 10 x 6 - Steel/Gray 3R SCREW COV 10X10X6 (10 x 10 x 6) Hammond PN C3R10106SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 60
Drop Ship Quantity: 60
Factory Lead Time: 55
|
1 - 2$39.60 3 - 4$38.90 5 - 9$38.30 ... |
|
|
C3R12106SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 12 x 10 x 6 - Steel/Gray 3R SCREW COV 12X10X6 (12 x 10 x 6) Hammond PN C3R12106SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 25
Drop Ship Quantity: 25
Factory Lead Time: 55
|
1 - 1$50.00 2 - 3$49.20 4 - 9$48.40 ... |
|
|
C3R12124SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 12 x 12 x 4 - Steel/Gray 3R SCREW COV 12X12X4 (12 x 12 x 4) Hammond PN C3R12124SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 200
Drop Ship Quantity: 200
Factory Lead Time: 55
|
1 - 1$42.60 2 - 3$41.90 4 - 9$41.20 ... |
|
|
C3R12128SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 12 x 12 x 8 - Steel/Gray 3R SCREW COV 12X12X8 (12 x 12 x 8) Hammond PN C3R12128SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 100
Drop Ship Quantity: 100
Factory Lead Time: 55
|
1 - 1$64.60 2 - 2$63.50 3 - 4$62.50 ... |
|
|
C3R242412SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 24 x 24 x 12 - Steel/Gray 3R SCREW COV 24X24X12 (24 x 24 x 12) Hammond PN C3R242412SC : UPC [62… |
Hammond Mfg.
Series C3RSC |
Total Stock: 40
Drop Ship Quantity: 40
Factory Lead Time: 55
|
1 - 1$218.30 2 - 2$214.80 3 - 4$211.30 ... |
|
|
C3R24246SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 24 x 24 x 6 - Steel/Gray 3R SCREW COV 24X24X6 (24 x 24 x 6) Hammond PN C3R24246SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 30
Drop Ship Quantity: 30
Factory Lead Time: 55
|
1 - 1$165.50 2 - 3$162.80 4 - 9$160.20 ... |
|
|
C3R24248SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 24 x 24 x 8 - Steel/Gray 3R SCREW COV 24X24X8 (24 x 24 x 8) Hammond PN C3R24248SC : UPC [623980… |
Hammond Mfg.
Series C3RSC |
Total Stock: 70
Drop Ship Quantity: 70
Factory Lead Time: 55
|
1 - 1$180.90 2 - 2$178.00 3 - 9$175.10 ... |
|
|
C3R363612SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 36 x 36 x 12 - Steel/Gray 3R SCREW COV 36X36X12 (36 x 36 x 12) Hammond PN C3R363612SC : UPC [62… |
Hammond Mfg.
Series C3RSC |
Total Stock: 20
Drop Ship Quantity: 20
Factory Lead Time: 55
|
1 - 1$504.00 2 - 4$497.80 5 - 9$491.40 ... |
|
|
C3R664SC
Enclosures
RoHS Compliant
Type 3R Screw Cover - 6 x 6 x 4 - Steel/Gray 3R SCREW COV 6X6X4 (6 x 6 x 4) Hammond PN C3R664SC : UPC [623980361291]… |
Hammond Mfg.
Series C3RSC |
Total Stock: 550
Drop Ship Quantity: 550
Factory Lead Time: 55
|
1 - 1$20.20 2 - 4$19.90 5 - 9$19.50 ... |
C3RSC
