Type 3R Painted Galvanized Steel Wallmount Enclosure C3R HCRMD Series Continuous Hinge Door with Screws
Application:
Designed for use as a wiring/junction box.
Provides protection against rain, sleet, snow and dripping water.
Standards:
UL-50 Type 3R
CSA Type 3R
Complies with
NEMA Type 3R
IEC 60529, IP24
Construction:
Formed and spot welded from 16 or 14 gauge galvanized steel.
Drip shield top and seam-free sides, front and back.
Stainless steel continuous hinge.
Cover fastened with captive plated screws.
Padlocking hasp.
Collar studs provided for mounting optional panels.
External mounting feet.
Oil resistant gaskets are permanently secured.
Finish:
Enclosure and cover are finished inside and out in ANSI 61 gray powder coating.
Displaying 1 - 10 of 23
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
C3R18186HCR
Enclosures
 RoHS Compliant
Type 3R Hinge Cover - 18 x 18 x 6 - Steel/Gray 3R HINGE COV 18X18X6 (18 x 18 x 6) Hammond PN C3R18186HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Total Stock: 15
Drop Ship Quantity: 15
Factory Lead Time: 55
|
1 - 1$196.00 2 - 2$192.80 3 - 9$189.80 ... |
|
|
C3R20208HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 20 x 20 x 8 - Steel/Gray 3R HINGE COV 20X20X8 (20 x 20 x 8) Hammond PN C3R20208HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Total Stock: 30
Drop Ship Quantity: 30
Factory Lead Time: 55
|
1 - 1$212.80 2 - 2$209.40 3 - 4$206.00 ... |
|
|
C3R242410HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 24 x 24 x 10 - Steel/Gray 3R HINGE COV 24X24X10 (24 x 24 x 10) Hammond PN C3R242410HCR : UPC [6… |
Hammond Mfg.
Series C3RHCRMD |
Total Stock: 6
Drop Ship Quantity: 6
Factory Lead Time: 55
|
1 - 1$277.00 2 - 3$272.60 4 - 9$269.00 ... |
|
|
C3R24248HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 24 x 24 x 8 - Steel/Gray 3R HINGE COV 24X24X8 (24 x 24 x 8) Hammond PN C3R24248HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Total Stock: 25
Drop Ship Quantity: 25
Factory Lead Time: 55
|
1 - 1$262.30 2 - 3$258.10 4 - 9$254.70 ... |
|
|
C3R30308HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 30 x 30 x 8 - Steel/Gray 3R HINGE COV 30X30X8 (30 x 30 x 8) Hammond PN C3R30308HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Total Stock: 40
Drop Ship Quantity: 40
Factory Lead Time: 55
|
1 - 1$440.30 2 - 2$433.30 3 - 9$427.60 ... |
|
|
C3R483616HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 48 x 36 x 16 - Steel/Gray 3R HINGE COV 48X36X16 (48 x 36 x 16) Hammond PN C3R483616HCR : UPC [6… |
Hammond Mfg.
Series C3RHCRMD |
Total Stock: 1
Drop Ship Quantity: 1
Factory Lead Time: 55
|
1 - 1$810.00 2 - 3$799.00 4 - 9$789.00 ... |
|
|
C3R16126HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 16 x 12 x 6 - Steel/Gray 3R HINGE COV 16X12X6 (16 x 12 x 6) Hammond PN C3R16126HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Factory Lead Time: 55
|
1 - 1$114.10 2 - 2$112.20 3 - 4$110.40 ... |
|
|
C3R16166HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 16 x 16 x 6 - Steel/Gray 3R HINGE COV 16X16X6 (16 x 16 x 6) Hammond PN C3R16166HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Factory Lead Time: 55
|
1 - 1$133.70 2 - 3$129.40 4 - 9$127.30 ... |
|
|
C3R181810HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 18 x 18 x 10 - Steel/Gray 3R HINGE COV 18X18X10 (18 x 18 x 10) Hammond PN C3R181810HCR : UPC [6… |
Hammond Mfg.
Series C3RHCRMD |
Factory Lead Time: 55
|
1 - 1$240.30 2 - 2$236.40 3 - 4$232.70 ... |
|
|
C3R20166HCR
Enclosures
RoHS Compliant
Type 3R Hinge Cover - 20 x 16 x 6 - Steel/Gray 3R HINGE COV 20X16X6 (20 x 16 x 6) Hammond PN C3R20166HCR : UPC [62398… |
Hammond Mfg.
Series C3RHCRMD |
Factory Lead Time: 55
|
1 - 1$151.10 2 - 3$146.20 4 - 9$143.90 ... |
