Type 3R Painted Galvanized Steel Enclosure C3R HCLO Series Lift-Off Hinge Door with Snap Latch
Application:
Designed for use as a wiring/junction box.
Provides protection against rain, sleet, snow and dripping water.
Standards:
UL-50 Type 3R
CSA Type 3R
Complies with
NEMA Type 3R
IEC 60529, IP24
Construction:
Formed and spot welded from 16 or 14 gauge galvanized steel.
Extended height door and seam-free sides, front and back.
Galvanized steel lift-off hinges with stainless steel pins.
Cover fastened securely with zinc plated draw pull catches.
Provisions for padlocking on zinc-plated draw pull catch.
Embossed mounting holes on back.
Seamless poured-in place gasket
Finish:
Enclosure and cover are finished in ANSI 61 gray powder coating.
Displaying 1 - 10 of 16
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
C3R1086HCLO
Enclosures
 RoHS Compliant
Type 3R Hinge Lift Off Cover - 10 x 8 x 6 - Steel/Gray 3R HINGE LIFT COV 10X8X6 (10 x 8 x 6) Hammond PN C3R1086HCLO :… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$65.00 2 - 2$63.90 3 - 4$62.90 ... |
|
|
C3R12106HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 12 x 10 x 6 - Steel/Gray 3R HINGE LIFT COV 12X10X6 (12 x 10 x 6) Hammond PN C3R12106HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$79.50 2 - 2$78.10 3 - 3$76.80 ... |
|
|
C3R12126HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 12 x 12 x 6 - Steel/Gray 3R HINGE LIFT COV 12X12X6 (12 x 12 x 6) Hammond PN C3R12126HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$85.90 2 - 3$84.50 4 - 9$83.10 ... |
|
|
C3R16126HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 16 x 12 x 6 - Steel/Gray 3R HINGE LIFT COV 16X12X6 (16 x 12 x 6) Hammond PN C3R16126HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$111.70 2 - 2$109.90 3 - 4$108.10 ... |
|
|
C3R16166HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 16 x 16 x 6 - Steel/Gray 3R HINGE LIFT COV 16X16X6 (16 x 16 x 6) Hammond PN C3R16166HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$142.60 2 - 3$137.90 4 - 9$135.70 ... |
|
|
C3R20166HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 20 x 16 x 6 - Steel/Gray 3R HINGE LIFT COV 20X16X6 (20 x 16 x 6) Hammond PN C3R20166HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$159.50 2 - 3$156.90 4 - 9$154.40 ... |
|
|
C3R20208HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 20 x 20 x 8 - Steel/Gray 3R HINGE LIFT COV 20X20X8 (20 x 20 x 8) Hammond PN C3R20208HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$201.20 2 - 2$198.00 3 - 9$194.80 ... |
|
|
C3R24208HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 24 x 20 x 8 - Steel/Gray 3R HINGE LIFT COV 24X20X8 (24 x 20 x 8) Hammond PN C3R24208HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$226.50 2 - 2$222.80 3 - 4$219.20 ... |
|
|
C3R24248HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 24 x 24 x 8 - Steel/Gray 3R HINGE LIFT COV 24X24X8 (24 x 24 x 8) Hammond PN C3R24248HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$255.40 2 - 2$251.20 3 - 4$247.20 ... |
|
|
C3R30248HCLO
Enclosures
RoHS Compliant
Type 3R Hinge Lift Off Cover - 30 x 24 x 8 - Steel/Gray 3R HINGE LIFT COV 30X24X8 (30 x 24 x 8) Hammond PN C3R30248HC… |
Hammond Mfg.
Series C3RHCLO |
Factory Lead Time: 55
|
1 - 1$293.50 2 - 3$288.80 4 - 9$285.10 ... |
C3RHCLO
