Type 3R Painted Galvanized Steel Junction Box C3RESCNK Series Screw Cover and without Knockouts
Application:o
Designed for use as a wiring/junction box.
Provides protection against rain, sleet, snow and dripping water.
Standards:
UL-50 Type 3R
CSA Type 3R
Complies with:
NEMA Type 3R
IEC 60529, IP24
Construction:
Formed and spot welded from 16 or 14 gauge galvanized steel.
Drip-shield top and seam-free sides, front and back.
Slip-on removable cover fastened with plated steel screws.
External mounting feet
Oil resistant gaskets are permanently secured
A bonding stud is provided on the door and a grounding stud is provided in the box.
Finish:
Enclosure and cover are finished in ANSI 61 gray powder coating.
Displaying 1 - 10 of 10
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
C3R10106ESCNK
Enclosures
 RoHS Compliant
N3R J Box, Screw Cover no K/O's - 10 x 10 x 6 - Steel/Gray N3R JBOX SCREW COVER NO K/O (10 x 10 x 6) Hammond PN… |
Hammond Mfg.
Series C3RESCNK |
Total Stock: 20
Drop Ship Quantity: 20
Factory Lead Time: 55
|
1 - 2$39.40 3 - 4$38.70 5 - 9$38.10 ... |
|
|
C3R18186ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 18 x 18 x 6 - Steel/Gray N3R JBOX SCREW COVER NO K/O (18 x 18 x 6) Hammond PN… |
Hammond Mfg.
Series C3RESCNK |
Total Stock: 4
Drop Ship Quantity: 4
Factory Lead Time: 55
|
1 - 1$104.50 2 - 2$102.80 3 - 9$101.10 ... |
|
|
C3R664ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 6 x 6 x 4 - Steel/Gray N3R JBOX SCREW COVER NO K/O (6 x 6 x 4) Hammond PN C3R6… |
Hammond Mfg.
Series C3RESCNK |
Total Stock: 150
Drop Ship Quantity: 150
Factory Lead Time: 55
|
1 - 1$20.10 2 - 4$19.80 5 - 9$19.40 ... |
|
|
C3R884ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 8 x 8 x 4 - Steel/Gray N3R JBOX SCREW COVER NO K/O (8 x 8 x 4) Hammond PN C3R8… |
Hammond Mfg.
Series C3RESCNK |
Total Stock: 72
Drop Ship Quantity: 70
Factory Lead Time: 55
|
1 - 1$27.90 2 - 2$27.40 3 - 9$27.00 ... |
|
|
C3R886ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 8 x 8 x 6 - Steel/Gray N3R JBOX SCREW COVER NO K/O (8 x 8 x 6) Hammond PN C3R8… |
Hammond Mfg.
Series C3RESCNK |
Total Stock: 50
Drop Ship Quantity: 50
Factory Lead Time: 55
|
1 - 1$31.30 2 - 2$30.80 3 - 9$30.30 ... |
|
|
C3R10104ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 10 x 10 x 4 - Steel/Gray N3R JBOX SCREW COVER NO K/O (10 x 10 x 4) Hammond PN… |
Hammond Mfg.
Series C3RESCNK |
Factory Lead Time: 55
|
1 - 2$33.90 3 - 4$33.30 5 - 9$32.80 ... |
|
|
C3R12124ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 12 x 12 x 4 - Steel/Gray N3R JBOX SCREW COVER NO K/O (12 x 12 x 4) Hammond PN… |
Hammond Mfg.
Series C3RESCNK |
Factory Lead Time: 55
|
1 - 1$42.30 2 - 3$41.60 4 - 9$40.90 ... |
|
|
C3R12126ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 12 x 12 x 6 - Steel/Gray N3R JBOX SCREW COVER NO K/O (12 x 12 x 6) Hammond PN… |
Hammond Mfg.
Series C3RESCNK |
Factory Lead Time: 55
|
1 - 1$50.80 2 - 3$49.90 4 - 9$49.10 ... |
|
|
C3R16166ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 16 x 16 x 6 - Steel/Gray N3R JBOX SCREW COVER NO K/O (16 x 16 x 6) Hammond PN… |
Hammond Mfg.
Series C3RESCNK |
Factory Lead Time: 55
|
1 - 1$93.90 2 - 2$92.30 3 - 9$90.80 ... |
|
|
C3R24246ESCNK
Enclosures
RoHS Compliant
N3R J Box, Screw Cover no K/O's - 24 x 24 x 6 - Steel/Gray 24X24X6 (24 x 24 x 6) Hammond PN C3R24246ESCNK : UPC… |
Hammond Mfg.
Series C3RESCNK |
Factory Lead Time: 55
|
1 - 1$162.00 2 - 3$159.40 4 - 9$156.80 ... |
