Type 4, 4X Polycarbonate Pushbutton Enclosure 1554 PB Series
Standards:
IP66
NEMA 4, 4X, 6, 6P, 12 & 13
UL94 5V
Construction:
Electronic instrument enclosures, designed for mounting printed circuit boards or DIN rail mounted components.
The polycarbonate material carries a UL flammability rating of UL94 5V and is suitable for outdoor use.
Lid and mounting holes are located outside of the gasket seal.
Lid is secured with self captivating M4 stainless steel machine screws (included), threaded into integral stainless steel bushings (for repetitive assembly & disassembly).
Heavy duty 16 gauge galvanized steel panels available (see chart)
All stainless steel hardware to avoid corrosion caused by dissimilar metals.
Gasket is a preformed, high temperature U.L. listed silicone rubber. Gasket is replaceable.
Gasketed lid with two piece “tongue & groove” construction provides protection against access of oil, dust and water.
Internal DIN rail mounting tabs.
Threaded (M3) integral brass inserts & standoffs designed for M3.5 or #6 self tapping screws for P.C. board or inner panel mounting in all but the smallest size.
Vertical P.C. card guides (for 1.5 mm thick P.C. boards) are molded in all but the smallest size
Finish:
Color is light gray (RAL 7035)
Accessories:
Optional Inner Panel
Heavy duty panels for mounting components
Galvanized 16 ga. steel.
Includes mounting hardware.
Displaying 1 - 10 of 25
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
1554PB3
Enclosures
 RoHS Compliant
N4X PB encl - 3 PB x 30.5mm - Polycarb 3 HOLE 30.5MM P-BUTTON ENCL. (7.9 x 4.7 x 3.5) Hammond PN 1554PB3 : UPC [62398… |
Hammond Mfg.
Series 1554PB |
Total Stock: 45
Drop Ship Quantity: 45
Factory Lead Time: 20
|
1 - 1$29.70 2 - 2$29.20 3 - 9$28.70 ... |
|
|
1554MPB1
Enclosures
RoHS Compliant
N4X PB encl - 1 PB x 22.5mm - Polycarb 1 HOLE 22.5MM P-BUTTON ENCL. (3.5 x 3.5 x 2.4) Hammond PN 1554MPB1 : UPC [6239… |
Hammond Mfg.
Series 1554PB |
Total Stock: 2
Factory Lead Time: 20
|
1 - 2$15.80 3 - 9$15.50 10 - 14$15.20 ... |
|
|
1554MPB15
Enclosures
RoHS Compliant
15 HOLE 22.5MM P-BUTTON 1554X (11.81 x 7.87 x 3.54) Hammond PN 1554MPB15 : UPC [623980406473] |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$61.80 2 - 2$60.70 3 - 4$59.70 ... |
|
|
1554MPB15A
Enclosures
RoHS Compliant
15 HOLE 22.5MM P-BUTTON 1554XA (11.81 x 7.87 x 4.72) Hammond PN 1554MPB15A : UPC [623980406480] |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$65.60 2 - 2$64.50 3 - 4$63.40 ... |
|
|
1554MPB1A
Enclosures
RoHS Compliant
1 HOLE 22.5MM P-BUTTON 1554EE (3.5 x 3.5 x 3.5) Hammond PN 1554MPB1A : UPC [623980401775] |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$17.90 2 - 4$17.50 5 - 9$17.30 ... |
|
|
1554MPB20
Enclosures
20 HOLE 22.5MM P-BUTTON 1554Y (11.81 x 9.45 x 3.74) Hammond PN 1554MPB20 : UPC [623980406763] |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$74.50 2 - 2$73.20 3 - 3$72.00 ... |
|
|
1554MPB20A
Enclosures
RoHS Compliant
20 HOLE 22.5MM P-BUTTON 1554YA (11.81 x 9.45 x 4.72) Hammond PN 1554MPB20A : UPC [623980406770] |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$76.80 2 - 2$75.50 3 - 3$74.30 ... |
|
|
1554MPB3
Enclosures
RoHS Compliant
N4X PB encl - 3 PB x 22.5mm - Polycarb 3 HOLE 22.5MM P-BUTTON ENCL. (7.9 x 4.7 x 3.5) Hammond PN 1554MPB3 : UPC [6239… |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$29.70 2 - 2$29.20 3 - 9$28.70 ... |
|
|
1554MPB4
Enclosures
RoHS Compliant
N4X PB encl - 4 PB x 22.5mm - Polycarb 4 HOLE 22.5MM P-BUTTON ENCL. (7.9 x 4.7 x 3.5) Hammond PN 1554MPB4 : UPC [6239… |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$30.70 2 - 2$30.20 3 - 9$29.70 ... |
|
|
1554MPB6
Enclosures
RoHS Compliant
N4X PB encl - 6 PB x 22.5mm - Polycarb 6 HOLE 22.5MM P-BUTTON ENCL. (9.5 x 6.3 x 3.5) Hammond PN 1554MPB6 : UPC [6239… |
Hammond Mfg.
Series 1554PB |
Factory Lead Time: 20
|
1 - 1$42.50 2 - 3$41.80 4 - 9$41.10 ... |
