Hawk Electronics
Filters1538
EMI/RFI Chokes 1538 Series
Features:
High saturation flux density ferrite rods.
1" long leads, tinned to within 1/8" of body.
Ideal for filtering or energy storage inductors.
Inductance measured at @ 1Khz. with 0 amps. D.C. current, typical inductance change is less than 5% @ twice rated current.
Ambient temperature range -60 C to +85 C
Displaying 1 - 10 of 24
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
1538M01
Enclosures
 RoHS Compliant
RF Choke, heavy duty hash choke, inductance 5uH, DC current 10A, 1538 series RF CHOKE Hammond PN 1538M01 : UPC [62398… |
Hammond Mfg.
Series 1538 |
Total Stock: 10
Factory Lead Time: 20
|
1 - 4$7.10 5 - 14$7.00 15 - 24$6.90 ... |
|
|
1538M02
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 10uH, DC current 9A, 1538 series RF CHOKE Hammond PN 1538M02 : UPC [62398… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 9$6.40 10 - 14$6.30 15 - 49$6.20 ... |
|
|
1538M03
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 27uH, DC current 7A, 1538 series RF CHOKE Hammond PN 1538M03 : UPC [62398… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 9$6.40 10 - 14$6.30 15 - 49$6.10 ... |
|
|
1538M04
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 50uH, DC current 5.6A, 1538 series RF CHOKE Hammond PN 1538M04 : UPC [623… |
Hammond Mfg.
Series 1538 |
Total Stock: 5
Factory Lead Time: 20
|
1 - 4$6.70 5 - 14$6.50 15 - 24$6.40 ... |
|
|
1538M05
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 100uH, DC current 4.9A, 1538 series RF CHOKE Hammond PN 1538M05 : UPC [62… |
Hammond Mfg.
Series 1538 |
Total Stock: 5
Factory Lead Time: 20
|
1 - 4$6.90 5 - 14$6.80 15 - 24$6.70 ... |
|
|
1538M06
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 150uH, DC current 4.6A, 1538 series RF CHOKE Hammond PN 1538M06 : UPC [62… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 9$5.30 10 - 24$5.20 25 - 74$5.10 ... |
|
|
1538M07
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 250uH, DC current 4A, 1538 series RF CHOKE Hammond PN 1538M07 : UPC [6239… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 4$6.90 5 - 14$6.80 15 - 24$6.60 ... |
|
|
1538M08
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 5uH, DC current 14A, 1538 series RF CHOKE Hammond PN 1538M08 : UPC [62398… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 9$6.40 10 - 14$6.30 15 - 49$6.20 ... |
|
|
1538M09
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 10uH, DC current 12A, 1538 series RF CHOKE Hammond PN 1538M09 : UPC [6239… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 4$6.80 5 - 14$6.60 15 - 24$6.50 ... |
|
|
1538M10
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 27uH, DC current 9A, 1538 series RF CHOKE Hammond PN 1538M10 : UPC [62398… |
Hammond Mfg.
Series 1538 |
Factory Lead Time: 20
|
1 - 4$7.60 5 - 14$7.50 15 - 24$7.40 ... |
1538
