Hawk Electronics
Filters1537
R.F. Chokes 1537 Series High Current
Features:
Large ferrite core for extended saturation point, optimum frequency range .01-2 Mhz.
1.5" long leads (+/- 0.1")
Test frequency 1 Khz.
Core length 1.25"
Coil is covered with vinyl insulation shrink sleeve.
Displaying 1 - 10 of 11
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
1537E
Enclosures
 RoHS Compliant
RF Choke, heavy duty hash choke, inductance 10uH, DC current 20A, 1537 series CHOKE 10 UH 20A Hammond PN 1537E : UPC… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537F
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 20uH, DC current 12.5A, 1537 series CHOKE 20 UH 12.5A Hammond PN 1537F :… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537G
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 30uH, DC current 8A, 1537 series CHOKE 30 UH 8A Hammond PN 1537G : UPC [6… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537H
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 40uH, DC current 5A, 1537 series CHOKE 40 UH 5A Hammond PN 1537H : UPC [6… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537J
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 50uH, DC current 3.2A, 1537 series CHOKE 50 UH 3.2A Hammond PN 1537J : UP… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537K
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 75uH, DC current 2A, 1537 series CHOKE 75 UH 2A Hammond PN 1537K : UPC [6… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537L
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 100uH, DC current 8A, 1537 series CHOKE 100 UH 8A Hammond PN 1537L : UPC… |
Hammond Mfg.
Series 1537 |
Total Stock: 2
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537M
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 250uH, DC current 5A, 1537 series CHOKE 250 UH 5A Hammond PN 1537M : UPC… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537N
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 500uH, DC current 3.2A, 1537 series CHOKE 500 UH 3.2A Hammond PN 1537N :… |
Hammond Mfg.
Series 1537 |
Total Stock: 5
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
|
|
1537P
Enclosures
RoHS Compliant
RF Choke, heavy duty hash choke, inductance 750uH, DC current 2A, 1537 series CHOKE 750 UH 2A Hammond PN 1537P : UPC… |
Hammond Mfg.
Series 1537 |
Factory Lead Time: 15
|
1 - 9$3.36 10 - 24$3.30 25 - 49$3.25 ... |
1537
