Audio Transformer Tube Driver - Interstage 126 Series
Features:
Designed for driver use ONLY in single ended tube output amplifiers. These units replace coupling capacitor circuits for improved sound.
Closed style with minimum 8" long leads.
All models use bifilar wound windings for exceptional coupling and bandwidth.
Minimum frequency response 20 Hz. - 20 Khz (+/- 1db max. ref. 1 Khz.).
The core is gapped to support the specified D.C. bias current.
Maximum working voltage - 400 VDC
Units are Hi-Pot tested at 1,000 VDC
Core uses Hi grade silicon laminations (29M6).
Units weight - 3 lbs. 2 oz.
Displaying 1 - 3 of 3
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
126A
Enclosures
 RoHS Compliant
Audio transformer, tube driver, interstage, for single ended tube amplifiers INTERSTAGE AUDIO TX Hammond PN 126A : UP… |
Hammond Mfg.
Series 126 |
Factory Lead Time: 20
|
1 - 1$90.90 2 - 2$89.40 3 - 9$87.90 ... |
|
|
126B
Enclosures
RoHS Compliant
Audio transformer, tube driver, interstage, for single ended tube amplifiers INTERSTAGE AUDIO TX Hammond PN 126B : UP… |
Hammond Mfg.
Series 126 |
Factory Lead Time: 20
|
1 - 1$90.90 2 - 2$89.40 3 - 9$87.90 ... |
|
|
126C
Enclosures
RoHS Compliant
Audio transformer, tube driver, interstage, for single ended tube amplifiers INTERSTAGE AUDIO TX Hammond PN 126C : UP… |
Hammond Mfg.
Series 126 |
Factory Lead Time: 20
|
1 - 1$90.90 2 - 2$89.40 3 - 9$87.90 ... |
126
