filter--iconPrice List

1650N

Hammond Mfg. | 1608-1650 | Audio Transformers
green-check-icon Total Stock: 1
yellow-timer-icon Factory Lead Time: 20
onlycheckmark RoHs Compliant
1608-1650
Output transformer, push-pull, 60W , primary 4,300 ct, 318 ma., secondary 4-8-16 AUDIO TX 4.3K OHM 60 WATT Hammond PN 1650N : UPC [623980301808]

$148.50

Min: 1  Mult: 1

Product Attributes

CAD File

Click Here

Series Photo

Click Here

Primary Impedance (ct Ohms)

4,300

Manufacturers Series Page

Click Here

Max ma DC Per Side

318

Maximum D.C. Per Side

318 ma.

Operation

Push-Pull Par. (2 or 4 Tubes)

Overall Dims

3.13 x 4.25 x 3.81

Pricing Note

Price change ~5.0% on 10/01/22

Secondary Impedance (Ohms)

4-8-16

Audio Watts (RMS)

60

Impedance (Ohms)

4,300 ct

Eccn

EAR99

Frequency response

30 Hz to 30 Khz at full rated power (+/- 1 db max. - ref. 1 Khz) minimum

Hammond Product Photo

Click Here

Leads

Insulated flexible 8" min

Suggested Tube Types

6L6GC, 807, 5881, EL34, 6146B, 6550B, KT88

Hammond Product Group

transformers

Hammond Product Type

transformer

Hammond Series

1608-1650

Lead-Time Weeks

4

UPC

623980301808

Standard Stock

Yes

Not available at this time.
