FiltersPZK3191
Screw type print terminals have been tried and tested for quite a number of years now and it is hard to imagine the printed circuit board without them. Available are the wire-protection, eccentric- top and strain-relief-clamp-principles. All of them are based on modular designs with two-pole and three-pole individual terminals which can be converted into multi-pole terminal block by using dovetail connections. This allows for flexible and economical inventory management. In addition, some series also provide “block design“ versions with a non-variable number of poles ranging from 2 to 12 which are specially suited for long pole applications.
Both the tension- and leg-spring-principles are available as alternatives. Due to their technical design, these principles are highly suited for extreme conditions such as heavy vibrations, a corrosive ambience and extreme fluctuations in temperature. The springs are operated by means of a screwdriver, actuation tools or lever. Constantly high clamping forces and good electric values can be achieved owing to perfect material quality
Displaying 1 - 10 of 104
| Title | Manufacturer | Availability | prices | Variations |
|---|---|---|---|---|
|
12111.3
PCB
Conta-Clip 7 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/7/2.54/ORG Cat-no: 12111.3 |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$2.19 100 - 149$2.14 150 - 499$2.10 ... |
|
|
12157.3
PCB
Conta-Clip 6 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/6/2.54-KD/ORG Cat-no: 12157.3… |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$2.17 100 - 149$2.12 150 - 499$2.08 ... |
|
|
12112.3
PCB
Conta-Clip 8 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/8/2.54/ORG Cat-no: 12112.3 |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 149$2.45 150 - 249$2.40 250 - 499$2.36 ... |
|
|
12158.3
PCB
Conta-Clip 7 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/7/2.54-KD/ORG Cat-no: 12158.3… |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 149$2.48 150 - 249$2.43 250 - 499$2.38 ... |
|
|
12114.3
PCB
Conta-Clip 10 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/10/2.54/ORG Cat-no: 12114.3 … |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$3.06 100 - 199$3.00 200 - 499$2.95 ... |
|
|
12160.3
PCB
Conta-Clip 9 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/9/2.54-KD/ORG Cat-no: 12160.3… |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$3.19 100 - 199$3.12 200 - 499$3.07 ... |
|
|
12115.3
PCB
Conta-Clip 11 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/11/2.54/ORG Cat-no: 12115.3 … |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$3.37 100 - 199$3.30 200 - 249$3.24 ... |
|
|
12161.3
PCB
Conta-Clip 10 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/10/2.54-KD/ORG Cat-no: 12161.3… |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$3.54 100 - 199$3.47 200 - 249$3.41 ... |
|
|
12116.3
PCB
Conta-Clip 12 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/12/2.54/ORG Cat-no: 12116.3 … |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$3.67 100 - 149$3.60 150 - 249$3.54 ... |
|
|
12162.3
PCB
Conta-Clip 11 Positions Tension-spring-principle Terminal Blocks PCB Orange ? PZK3191/11/2.54-KD/ORG Cat-no: 12162.3… |
CONTA-CLIP
Series PZK3191 |
Factory Lead Time: 240
|
50 - 99$3.89 100 - 149$3.82 150 - 249$3.75 ... |
PZK3191
