RRA22H3BBRHN

ZF (Formerly Cherry) | PR | Ultra-Miniature
green-check-icon Total Stock: 325
blue-timer-icon Drop Ship Quantity: 325
yellow-timer-icon Factory Lead Time: 120
onlycheckmark RoHs Compliant
PR
Round 10A Single Pole panel mount switch with 0.187 (4.8) Quick-connect terminals and Black Housing and Red Actuator. Markings are Blank

$2.02

Min: 1  Mult: 1

Product Attributes

Overall Dims (In)

0.85 x 0.85 x 0.85

Feature 6

Mechanical life min. 100,000 operations

Feature 7

Splash-proof option available

Feature 5

Industry-standard cut-out dimensions

Feature 4

Available in a wide variety of colours

Feature 3

Lighted and non-lighted versions available

Feature 2

Single-pole and double-pole configurations

Feature 1

High current switching in a compact round package

MFG-PackageSize

400

Contact Rating

10A 125VAC 1/4HP, 8A 250VAC 1/4HP cULus, 10(4)A 250V~T125/55 VDE

Switch Action

Single Pole

Switch Function

On-Off

Terminal Type

0.187 (4.8) Quick-connect

Actuator Type

Round

Actuator Marking

Blank

Housing Color

Black

Actuator Color

Red

Lighted

Lighted 12VDC Incandescent

Splashproof

NO Rocker Boot

Actuator Material

Nylon 66 94V-2

Temperature Range

-20C to + 65C

Spring Material

Steel Wire

RoHS

Yes

Moveable Arm Material

Copper Alloy

Mechanical Life

Minimum 100,000 operations

Insulation Resistance

100 Mega Ohms min at 500 VDC

Initial Contact Resistance

0.020 Ohms max

Electrical Life at Rated Load (VDE)

10,000 minimum operations

Electrical Life at Rated Load (UL)

6,000 minimum operations

Dielectric Strength

1,000VAC for 1 min

Contact Material

Silver Alloy

Base Material

Nylon 66 94V-2

Terminal Material

Tin-Plated Copper Alloy
