SRB24A2HBBNN

ZF (Formerly Cherry) | SRB | Miniature
green-check-icon Total Stock: 4
yellow-timer-icon Factory Lead Time: 120
onlycheckmark RoHs Compliant
SRB
ZF Single Pole On-Off-On Rocker Switch with Curved Black Actuator and I O II (horizontal) markings. Switch has 4.8 mm (.187) Quick Connects Terminals and Black Color Housing

$0.544

Min: 1  Mult: 1

Product Attributes

Switch Function

On-Off-On

EN61058-1 Rating

10 (4) A 250VAC ~(mu) T125/55

Electrical Life (VDE)

10,000 Cycles

Terminal Type

4.8 mm (.187) Quick Connects

Actuator Type

Curved

Actuator Marking

I O II (horizontal)

Housing Color

Black

Actuator Color

Black

Lighted

Non-Lighted

Body Type

No Rocker Boot

Dielectric Strengt

1000 VAC for 1 Min

Self Locking Tab

Yes

RohS

Compliant

Operating Temp

-20C to +65C

Mechanical Life

100,000 Cycles

Mat'l Terminals

Tin-Plated Copper Alloy

Mat'l Spring

Steel Wire

Mat'l Base

Nylon 66 94V-2

Mat'l Actuator

Nylon 66 94V-2

Insulation Resist.

100 MOhms at 500 VDC

Inrush Rating

48 A

Initial Resist.

0.020 Ohms Max

Electrical Life UL

6,000 Cycles

UL Gen. Rating

10A 125 VAC / 6A 250 VAC
