Product Attributes

Withdrawl Force-Min (N)

3.614

Operating Temperature-Min

-55 Cel

Operating Temperature-Max (Cel)

105

Number of Rows Loaded

1

Mounting Type

CABLE

Mounting Option 1

LOCKING

Mixed Contacts

NO

MIL Conformance

NO

Mating Contact Pitch (inch)

0.1

Manufacturer Series

641238

Option

GENERAL PURPOSE

Polarization Key

POLARIZED HOUSING

Wire Size-Min

24 AWG

Wire Size-Max

24 AWG

UL Flammability Code

94V-2

Total Number of Contacts

4

Terminal Type

IDC

Sub Category

Headers and Edge Type Connectors

Status

Active

Reliability

COMMERCIAL

Reference Standard

UL, CSA

JESD-609 Code

e3

Insulator Material

NYLON

Insulator Color

WHITE

Contact Material

COPPER ALLOY

Contact Gender

FEMALE

Contact Finish - Termination

TIN

Contact Finish - Mating

GOLD (30) OVER NICKEL

Contact Design

PREASSEM CONN

Connector Type

BOARD CONNECTOR

Body/Shell Style

RECEPTACLE

Body Diameter

0.4000 inch

Body Depth

0.5200 inch

Contact Pattern

RECTANGULAR

Contact Resistance

10 mohm

Insulation Resistance

5.00E9 ohm

Insertion Force-Max (N)

8.896

IEC Conformance

NO

Filter Feature

NO

EU RoHS Compliant

Yes

Durability

25 Cycles

DIN Conformance

NO

Dielectric Withstanding Voltage (V)

750VAC

Contact Style

SQ PIN-SKT

Body Breadth

0.2750 inch
