Price List
104257-5
Total Stock: 6200
Factory Lead Time: TBD
RoHs Compliant
06 MTE RCPT HSG SR LATCH .100
Hawk Electronics
Total Stock: 6200
Factory Lead Time: TBD
RoHs Compliant
Product Attributes
Additional Feature
LATCHED, POLARIZED
Mating Contact Pitch (inch)
0.1
Mating Information
MULTIPLE MATING PARTS AVAILABLE
MIL Conformance
NO
Mixed Contacts
NO
Mounting Option 1
POLARIZED LCK
Mounting Type
CABLE
Number of Rows Loaded
1
Operating Temperature
-65 C to 105C
Option
GENERAL PURPOSE
Polarization Key
ENDS
Reference Standard
UL, CSA
Reliability
COMMERCIAL
Status
Active
Sub Category
Headers and Edge Type Connectors
Terminal Type
IDC
Total Number of Contacts
6
Manufacturer Series
104257
Insulator Material
THERMOPLASTIC
Body Breadth
0.0980 inch
Body Depth
0.6000 inch
Body Diameter
0.5980 inch
Body/Shell Style
RECEPTACLE
Connector Type
BOARD CONNECTOR
Contact Finish - Mating
NOT SPECIFIED
Contact Gender
FEMALE
Contact Material
NOT SPECIFIED
Contact Pattern
RECTANGULAR
Dielectric Withstanding Voltage (V)
600VAC
DIN Conformance
NO
EU RoHS Compliant
Yes
Filter Feature
NO
IEC Conformance
NO
Insulation Resistance
5.00E9 ohm
Insulator Color
BLACK
UL Flammability Code
94V-0
Series Attributes
Not available at this time.
