REMKE

403E0066AA9

REMKE | 40-E-AA9 | Molded Circular
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
Dual Key Shielded to Coupler Micro-Link Plug Assembly, TPE, Male, 3 pole, 6.6', 22 AWG. Remke Part Number: 403E0066AA9 UPC Code (785411806013)

$36.30

Min: 1  Mult: 1

Product Attributes


Click Here

BRAND

Remke

Photo-M1

Click Here

PRODUCT LENGTH (IN)

2.02

PRODUCT WIDTH (IN)

0.57

Maximum Operating Temperature C

105

Cord set Configuration

Straight

Product Photo

Click Here

PRODUCT NUMBER

403E0066AA9

PRODUCT LINE

Micro and Mini Connectors

PRODUCT GROUP

Industrial Power Cordsets

PRODUCT CATEGORY

Molded Connectors and Cordsets

Wire Gauge

AWG 22.00

Pin Count (Number of Poles)

3

Parent Category

Remke Products, Micro and Mini Connectors

ORing Material

Nitrile Rubber

REACH Compliant

1

Wiring Color Code

Auto CC

RFEMI Protection

Yes

Width in

0.57

WARRANTY

1 Year

Voltage Rating DC

300

Voltage Rating AC

250

Voltage Rating (DC)

300

Voltage Rating (AC)

250

UPC

785411806013

UNSPSC

32151902

TITLE

Dual Key Shielded to Coupler Micro-Link Plug Assembly, TPE, Male, 3 pole, 6.6', 22 AWG

Temperature Application

Standard Temperature

SKU

403E0066AA9

Shielding Braiding

1

RoHS Compliant

TRUE

ORing

1

NEMA Rating

6P

Molded Connector Type

Plug (Male)

Included O-Ring

Yes

Included Locknut

No

Has Approval

FALSE

GTIN

785411806013

DATE LAST UPDATED

3/20/24

Current Rating (AMPS)

5

Coupling Nut Plating

Clear Anodized

Coupling Nut Material

Brass

COUNTRY OF ORIGIN

US

Cordset Configuration

Straight

Competitors

7.85412E+11

Additional Title

Dual Key Shielded to Coupler Micro-Link Plug Assembly, TPE, Male, 3 pole, 6.6', 22 AWG

Additional Strain Relief Mesh

No

Insert Material

Nylon

IP Rating

IP67

Max Temperature (C)

105

Min Temperature (F)

-40

Min Temperature (C)

-40

Maximum Operating Temperature F

221

Max Temperature (F)

221

Minimum Operating Temperature F

-40

Material

PUR

MANUFACTURER

NSI Industries

Locknut

0

Length in

2.02

Is Quote Only

FALSE

IS ACTIVE

TRUE

Minimum Operating Temperature C

-40

Current Rating amps

5

REMKE Categories

Industrial Molded Connectors>Micro Link M12 Connectors & Cordsets>Micro M12 Cordsets & Cable Assemblies

RF EMI Protection

1
