PLT5H-L0

Panduit | In Stock | Panduit-Electrical
green-check-icon Total Stock: 900
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
Factory Standard Pack = 50: Cable Tie, 17.7 Inches (450 mm) Length, Heavy, 175 Minimum Loop Tensile Strength, Weather Resistant Nylon 6.6, Black. Material Flammability Rating of HB. Weather Resistant material has greater resistance to damage caused by ultraviolet light. Indoor or outdoor use. One-piece construction for consistent performance and reliability. Low thread force.: Prices available while supplies last.

$1.03

Min: 1  Mult: 1

Product Attributes

Width (In.)

0.350

Standards

UL Compliant 62275, UL Listed #E56854, UL Recognized #E56854

Stable to Vibration

No

Shelf Life

1440

Sell Pack Packaging Description

BAG

Restricted Use of Hazardous Substances

N

Plenum-Rated

No

Operating Temperature

-76°F (-60°C) - 185°F (85°C)

NAFTA Country of Origin

US

MSDS Indicator

N

Min. Loop Tensile Strength Lbs. (N)

175 (778)

Min. Loop Tensile Strength (N)

778

Std Carton Height

7.3

Std Carton Length

22.9

Std Carton Width

10.4

UV Resistant

Yes

UNSPSC

39121703

Unit Weight

.024

Unit Volume

.001961

UL Recognized

No

UL Listed (File #E56854)

No

Tool

GTHE, GS4H, GS4EH, PTH, STH2, ST3EH

Thickness (In.)

0.078

Surface Treatment

Untreated

Suggested Index Terms

Cable ties, zip ties, tie-wraps

Stud Size

No

Min. Loop Tensile Strength (Lbs.)

175

Min. Bundle Diameter (In.)

0.19

Max. Continuous Use Temperature

185°F (85°C)

Head Width (In.)

0.560

Head Height (In.)

0.340

Hazardous Material

N

Environment

Outdoor (UV Resistant)

CSA Certified

No

Cross Section

Heavy

Country of Origin Description

Costa Rica

Continuous Use Temperature Range

-76°F (-60°C) - 185°F (85°C)

Color

Black

Certificate of Conformity

N

CE Marking

Yes

CE Compliant

Yes

Installation Temperature

-4°F (-20°C) - 32°F (0°C)

Length (In.)

17.7

Locking Style

Locking

Max. Bundle Dia. (In.)

5.00

Material Grade

Polyamide PA

Material Flammability Rating

HB

Material

Weather Resistant Nylon 6.6

Bundle Diameter Range In. (mm)

0.19 (4.8) - 5.00 (127)

Master Weight

12

Marker/Flag Tie Labeling Area

None

Master Pack Quantity

10

Markers Per Card

No

UPC

7498354103

TYPE

Locking Tie

Size

Approx 5.0"

Cross Section (IPNS)

Heavy

Screw Hole Size

None

Package Size

50

Material/Color

Weather Resistant Nylon 6.6 / Black

Design Feature

One-piece locking wedge provides consistent, reliable performance

Threading Force

Low - reduces operator fatigue
