PLM2S-D4Y

Panduit | In Stock | Panduit-Electrical
green-check-icon Total Stock: 500
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
Factory Standard Pack = 500: Marker Tie, Wrap Style, 7.4 Inches (188 mm) Length, Standard, Nylon, Yellow. For indoor use. Used to fasten and identify bundles at the same time. One-piece construction for consistent performance and reliability. Can be marked with Panduit Marker Pens (sold separately) or Custom imprinted with text, symbols or trademarks available using Panduit Custom Hot Stamping Service. Curved tip is easy to pick up from flat surfaces and allows faster initial threading.: Prices

$0.32

Min: 1  Mult: 1

Product Attributes

Width (In.)

0.185

Standards

UL Compliant 62275, UL Listed #E56854, UL Recognized #E56854

Stable to Vibration

Yes

Shelf Life

1440

Sell Pack Packaging Description

BAG

Restricted Use of Hazardous Substances

N

Plenum-Rated

No

Panduit Die Color & Die No.

Wrap

Operating Temperature

-76°F (-60°C) - 185°F (85°C)

Note

PLM2S-D4Y replaces PLM2S-D4

MSDS Indicator

N

Min. Loop Tensile Strength Lbs. (N)

50 (222)

Std Carton Height

2.3

Std Carton Length

12.5

Std Carton Width

10.1

UV Resistant

false

UNSPSC

39121703

Unit Weight

.0032

Unit Volume

.000336

UL Recognized

No

UL Listed (File #E56854)

Yes

Tool

GTS-E, GS2B, GTH-E, GS4H, PTS, PTH, PPTS, STS2, STH2

Thickness (In.)

0.052

Surface Treatment

Untreated

Suggested Index Terms

Cable ties, zip ties, tie-wraps

Stud Size

Yes

Min. Loop Tensile Strength (N)

222

Min. Loop Tensile Strength (Lbs.)

50

Min. Bundle Diameter (In.)

0.37

Head Height (In.)

0.220

Hazardous Material

N

Environment

Indoor

CSA Certified

Yes

Cross Section

Standard

Country of Origin Description

Singapore

Continuous Use Temperature Range

-76°F (-60°C) - 185°F (85°C)

Color

Yellow

Certificate of Conformity

N

CE Marking

Yes

CE Compliant

Yes

Head Width (In.)

0.320

Installation Temperature

-4°F (-20°C) - 32°F (0°C)

Length (In.)

7.4

Mil. Std. Part Number

MS3368-1-4A

Max. Continuous Use Temperature

185°F (85°C)

Max. Bundle Dia. (In.)

1.75

Material Grade

Polyamide PA

Material Flammability Rating

UL 94V-2

Material

Nylon 6.6

Master Weight

32

Master Pack Quantity

20

Marker/Flag Tie Labeling Area

Adjacent to bundle

Marker Write-On Area (In.)

0.44 x 0.87

Locking Style

Locking

Bundle Diameter Range In. (mm)

0.37 (9.5) - 1.75 (45)

UPC

7498344734
