MD240-12A-1CS

Micron Industries | Din-Rail | Din Rail
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
Power Supply, Din Rail Mount, Metal Case, Output 190W x 12VDC, Input 88-264VAC, 1-Phase, 64.0MM Width, UL 508/60950, cUL, CE EN61000, UL 1604/ISA 12.12.01 Class 1 DIV 2

$138.60

Min: 1  Mult: 1

Product Attributes

OVERALL Dims

(4.59 x 2.52 x 4.90)

Brand

DINergy

Style

Standard

Standards

UL / cUL: UL 508 Listed, UL 60950-1 Recognized, ISA 12.12.01 (Class 1, Division 2, Groups A, B, C & D), CE to EN61000

Short Description

DC Power Supply 11.4-14.5VDC

Product Type

DC Power Supply

Phase

1

Peak Current (A)

23.75

Output Voltage Range (VDC)

11.4-14.5

Output Voltage (VDC)

12

Output Power (Watts)

190

Output Current Range (A)

16.00-13.00

Output Current (A)

15.833

Mounting Style

Din Rail Mount

Input Voltage VDC

120-375

Input Voltage VAC

88-264

Hz

47-63

Case Type

Metal Case

Warranty

3 Years

Not available at this time.
