Factory Lead Time: TBD
RoHs Compliant
This item is currently subject to a tariff of 15%
AFI
Compact size - 7.625" L x 4" W x 2" D
Stall torque: 109 in-lbs (125 kgf/cm: 12.3 Nm)
Stall current: 11.5-13.0 amps
No load current: 0.5-1.2 amps
Bulk
035028380100
Use with three-position switch (not included)
Stainless steel fasteners and mounting bracket
Retail version includes 5 amp fuse and holder
Adjustable right or left self parking, coast to park
Solid brass knurled drive nut with brass and stainless steel drive shaft
Two-speed motor, can be operated as one speed
Heavy-duty motor with right angle drive
Factory pre-set sweep of 80 degree or 110 degree adjustable to 45 degree, 60 degree, 80 degree or 110 degree
0.625" diameter shaft (16 mm)
Corrosion-resistant casing
Available in 3 shaft lengths: 1.5", 2.5" and 3.5" (includes .5" length of knurled arm fitting)
Bulk
012035028380100
Price change of approx. 15.0% Effective 07/01/23
Active
035028380100
2.7
43.2
1
Active
15%
Not available at this time.
Price List
