Intermatic

GMXQT-O-120

Intermatic | GM | Surface Mount Timers
green-check-icon Total Stock: 1
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
document_IMATC_GMXQT-O-120
The GMX series time switches are universal mechanical time switches. They are a low cost alternative for applications that do not require more than 21 A or 2 HP @ 240 VAC. The timer is mounted in a UL Type 1 indoor or Type 3R outdoor plastic enclosure. The GMX is a light-duty commercial time switch ideal for 24, 120 or 208/240 VAC single-phase general applications.

$130.48

Min: 1  Mult: 1

Product Attributes

Application Compatibilities

Incandescent;Fluorescent;CFL;LED

Maximum Cycle Time

24 hrs

Mechanism Type

Electromechanical

Minimum Cycle Time

15 min

Mounting Options

Wall

Operating Humidity

0 to 95%, Non-condensing

Operating Temperature Max F

131

Operating Temperature Min F

-4

Operating Temperature with Battery Backup

-4° F to 131° F (-20° C to 55° C)

Power Consumption Max Va

1

Shortest Switching Time

ON/OFF 15 minutes

Switch Type

SPDT

Timing Interval

15 min

UL Certification

cULus

UPC

078275153219

WarrantyPeriod

1-Year limited

Wire Size Max

#12 AWG

Wiring Option

Screw terminal accepts up to #12 AWG wire

Input Voltage Ranges

120 VAC, 50/60 Hz

GTIN

00078275153219

Battery Service Type

Rechargeable

Battery Type

NiMh

Brand

Domestic Intermatic

Clock Drive Type

Quartz

DataSheet

Click Here

Enclosure Type

Outdoor type 3R plastic

Backup Protection Time

72 Hours

Feature1

21 A SPDT Switch

Feature2

UL Type 1 indoor or Type 3R outdoor plastic enclosure

Feature3

Manual 3-way override

Feature4

Captive trippers with 15-minute intervals on 24-hour models and 2-hour intervals on 7-day models

Feature5

True clock face, easy to set

Feature6

Finger-safe terminals

Feature7

Enclosure provides space for field-added contactor or other accessories

Feature8

Synchronous drive or quartz drive ("Q" models) with self-charging battery backup

Backup Type

72-hour Carry-over;Battery;Self-recharging

MFG-Link

Click Here

Photo-1

Click Here

LifeCycle

Production
