Intermatic

K4421M

Intermatic | KP | Photocontrols
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
document_IMATC_K4421M
These photocontrols install on standard outdoor light fixtures and electrical boxes with 1?2"-14 NPSM thread or 7?8" knock-out holes for dusk-to-dawn ON/OFF control of outdoor lighting.

$17.78

Min: 1  Mult: 1

Product Attributes

Wiring Option

Wire leads

Photocontrol Photocell Type

Cadmium Sulfide

Photo-3

Click Here

Photo-2

Click Here

Photo-1

Click Here

Other Certifications

Title 20

Operating Temperature Min F

-40

Operating Temperature Max F

158

MFG-Link

Click Here

Photocontrol Sensor Location

Side

Photocontrol Style

Stem Mount

Photocontrol Switch Type

Mechanical Bimetal

Wire Size Max

#18 AWG

Wire Lead Length In

9

WarrantyPeriod

2-Year limited

Usage Environments

Outdoor

UPC

078275105997

UL Certification

UL

Sensor Time Delay

30 sec to 90 sec

Photocontrol Type

Thermal

Magnetic Ballast Load Ratings Ranges

8.3 A, 1000 VA

Magnetic Ballast Load Ratings

8.3 A, 1000 VA

Expected Lifetime Years

5

Expected Lifetime Operations

3650

Datasheet

Click Here

CSA Certification

cCSAus

Cover Color

Gray

Brand

Intermatic

Application Compatibilities

HID;Fluorescent;Incandescent

Activation On

1 to 5 fc

Fail Mode

ON

Feature1

Mechanical bimetal switch with Cadmium Sulfide photocell

Feature2

Delay feature prevents unwanted OFF switching

Input Voltage Ranges

120 VAC, 50/60 Hz

Housing Material

Die-Cast Zinc

GTIN

00078275105997

Feature6

#18 AWG, 9" wire leads

Feature5

Washer gasket and locking nut included

Feature4

1⁄2"-14 NPSM threaded stem

Feature3

Die-cast metal housing

Activation Off

3 to 15 fc

LifeCycle

Production
