Intermatic

T104M

Intermatic | TP | Mechanical Timers
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
The T100 Series Mechanical Time Switch has proven it can stand the test of time. These dependable time switches can handle electrical loads up to 40 A per pole and allow for up to 12 ON/OFF operations per day. A manual override switch provides added convenience.

$70.18

Min: 1  Mult: 1

Product Attributes

Application Compatibilities

LED;HID

Number Of Circuits

1

Operating Temperature Max F

130

Operating Temperature Min F

-40

Other Certifications

LED

Photo-1

Click Here

Pilot Duty Load Ratings

1000 VA, 120 VAC, 60 Hz;1000 VA, 208 VAC, 60 Hz;1000 VA, 240 VAC, 60 Hz;1000 VA, 277 VAC, 60 Hz

Power Consumption Max W

3 W

Skipper Wheel Operation Mode

Not Included

Switch Type

DPST

Timing Interval

1 hr

UL Certification

cULus

UPC

078275000261

WarrantyPeriod

1-Year limited

Wire Size Max

#8 AWG

Minimum On Off Time

1 hour

MFG-Link

Click Here

Maximum On Off Operations

12

Brand

Intermatic

CSA Certification

cCSAus

Enclosure Type

N/A - Mechanism only

Feature1

Highest motor load ratings in the industry

Feature2

12 ON/OFF operations per day

Feature3

One ON and one OFF tripper included

Feature4

Can be installed in most Intermatic enclosures

Feature5

Available with pool heater protection

Feature6

Teeter-type terminals for multiple load connections

Feature7

Can be installed in most Intermatic enclosures

GTIN

00078275000261

Heater Control Output

10 A, 250 VAC MAX, 60 Hz

Input Voltage Ranges

208-277 VAC, 60 Hz

Wire Size Min

#14 AWG

LifeCycle

Production
