Product Attributes

Application Compatibilities

LED;HID

Minimum On Off Time

1 hour

Number Of Circuits

1

Operating Temperature Max F

130

Operating Temperature Min F

-40

Other Certifications

LED

Pilot Duty Load Ratings

1000 VA, 120-240 VAC, 60 Hz

Power Consumption Max W

3 W

Skipper Wheel Operation Mode

Not Included

Switch Type

DPST

UL Certification

cULus

UPC

078275000254

WarrantyPeriod

1-Year limited

Wire Size Max

#8 AWG

Maximum On Off Operations

12

Wire Size Min

#14 AWG

Brand

Intermatic

CSA Certification

cCSAus

DataSheet

Click Here

Enclosure Type

N/A - Mechanism only

Feature1

Highest motor load ratings in the industry

Feature2

12 ON/OFF operations per day

Feature3

One ON and one OFF tripper included

Feature4

Can be installed in most Intermatic enclosures

Feature5

Available with pool heater protection

Feature6

Teeter-type terminals for multiple load connections

Feature7

Can be installed in most Intermatic enclosures

GTIN

00078275000254

Heater Control Output

10 A, 250 VAC MAX, 60 Hz

Input Voltage Ranges

120 VAC, 60 Hz

MFG-Link

Click Here

Photo-1

Click Here

LifeCycle

Production
