filter--iconPrice List

Product Attributes

Application Compatibilities

LED

Number Of Circuits

1

Operating Temperature Max F

130

Operating Temperature Min F

-40

Operation Mode

24 hour

Other Certifications

LED

Pilot Duty Load Ratings

1000 VA, 120-240 VAC, 60 Hz

Power Consumption Max W

3 W

Switch Type

SPST

UL Certification

cULus

UPC

078275026308

WarrantyPeriod

1-Year limited

Maximum On Off Operations

12

Wiring Option

Terminals

DataSheet

Click Here

Enclosure Type

Outdoor type 3R metal

Feature1

Highest motor load ratings in the industry

Feature2

12 ON/OFF operations per day

Brand

Intermatic

Feature3

One ON and one OFF tripper included

Feature4

Available with pool heater protection

Feature5

Teeter-type terminals for multiple load connections

GTIN

00078275026308

Heater Control Output

10 A, 250 VAC MAX, 60 Hz

Input Voltage Ranges

120 VAC, 60 Hz

CSA Certification

cCSAus

MFG-Link

Click Here

Photo-1

Click Here

LifeCycle

Production

Not available at this time.
