Hawk Electronics
Price List
RoHs Compliant
Product Attributes
Tariff 301
This item is currently subject to a tariff of 25%
Packaging
Tray
RATED VOLTAGE
24 vdc
OPERATING VOLTAGE
15 ~ 28 vdc
OPERATING TEMPERATURE
-20 TO +60°C
MOUNTING DIMENSIONS
14.0 mm
MAX CURRENT
25 mA
TERMINAL TYPE
2 Pins
FRAME DIAMETER
28.0 mm
FRAME DEPTH
19.0 mm
SOUND LEVEL OUTPUT
95dB @ 30 cm
RESONANT FREQUENCY
2800 ± 200 Hz
Rohs Status
RoHS3 Compliant
Reach
Reach Upon Request
CIRCUIT
WITH CIRCUIT
TONE MODE
CONTINUOUS
Outer Pack Qty
1000
Series Attributes
Not available at this time.
