Hawk Electronics
Price List
RoHs Compliant
Product Attributes
Tariff 301
This item is currently subject to a tariff of 25%
OPERATING TEMPERATURE
-20 TO +70°C
RATED VOLTAGE
12 vdc
Packaging
Tray
OPERATING VOLTAGE
8 ~ 15 vdc
TERMINAL TYPE
2 Pins
SOUND LEVEL OUTPUT
90dB @ 10 cm
MOUNTING DIMENSIONS
7.6 mm
MAX CURRENT
40 mA
FRAME DIAMETER
16.0 mm
FRAME DEPTH
14.0 mm
COIL RESISTANCE
115 ± 17 ohm
COIL IMPEDANCE
200 ohm
RESONANT FREQUENCY
2048 Hz
CIRCUIT
Without Circuit
Rohs Status
RoHS3 Compliant
Reach
Reach Upon Request
TONE MODE
CONTINUOUS
Outer Pack Qty
2000
Series Attributes
Not available at this time.
