Product Attributes
Tariff 301
This item is currently subject to a tariff of 25%
OPERATING TEMPERATURE
-40 TO +85°C
RATED VOLTAGE
5 vdc
Packaging
Tray
OPERATING VOLTAGE
3 ~ 8 vdc
TERMINAL TYPE
2 Pins
SOUND LEVEL OUTPUT
85dB @ 10 cm
MOUNTING DIMENSIONS
6.5 mm
MAX CURRENT
40 mA
FRAME DIAMETER
12.0 mm
FRAME DEPTH
9.5 mm
COIL RESISTANCE
47 ± 5 ohm
COIL IMPEDANCE
80 ohm
RESONANT FREQUENCY
2400 Hz
CIRCUIT
Without Circuit
Rohs Status
RoHS3 Compliant
Reach
Reach Upon Request
TONE MODE
CONTINUOUS
Outer Pack Qty
5000
Series Attributes
Not available at this time.
