Product Attributes
Tariff 301
This item is currently subject to a tariff of 25%
Packaging
Tray
RATED VOLTAGE
12 vdc
OPERATING VOLTAGE
3 ~ 15 vdc
OPERATING TEMPERATURE
-30 TO +110°C
MOUNTING DIMENSIONS
15.0 mm
MAX CURRENT
10 mA
TERMINAL TYPE
2 Pins
FRAME DIAMETER
24.0 mm
FRAME DEPTH
11.0 mm
SOUND LEVEL OUTPUT
85dB @ 30 cm
RESONANT FREQUENCY
3800 ± 500 Hz
Rohs Status
RoHS3 Compliant
Reach
Reach Upon Request
CIRCUIT
WITH CIRCUIT
TONE MODE
CONTINUOUS
Outer Pack Qty
2000
Series Attributes
Not available at this time.
