Hawk Electronics
Price List
RoHs Compliant
Product Attributes
Tariff 301
This item is currently subject to a tariff of 25%
Packaging
Tray
RATED VOLTAGE
20 Vp-p
OPERATING VOLTAGE
1 ~ 20 Vp-p
OPERATING TEMPERATURE
-20 TO +70°C
MOUNTING DIMENSIONS
7.6 mm
MAX CURRENT
1 mA
FRAME DIAMETER
13.8 mm
TERMINAL TYPE
2 Pins
FRAME DEPTH
6.8 mm
SOUND LEVEL OUTPUT
80dB @ 10 cm
ELECTROSTATIC CAPACITY
13000 pF ± 30%
RESONANT FREQUENCY
4000 ± 500 Hz
Rohs Status
RoHS3 Compliant
Reach
Reach Upon Request
CIRCUIT
Without Circuit
TONE MODE
CONTINUOUS
Outer Pack Qty
5000
Series Attributes
Not available at this time.
