Product Attributes

Cable Dia Range (In)

(0.260 x 0.545)

Cable Dia Range (mm)

(6.6 x 13.8)

NEMA Ratings

NEMA 4. 4X. 6 and 6P

Min Cable Dia. (mm)

6.6

Max Cable Dia. (mm)

13.8

Max Cable Dia. (In)

0.545

IP Rating

IP 68 (70 PSI. 5 BAR)

Min Cable Dia. (In)

0.260

Hardware

Nylon Nut Included

Orientation

Straight-Thru With Pigtail

Temperature Range

-20C to + 100C

Nut Flat Width (mm)

26.9

Nut Flat Width (In)

1.06

Max Length (mm)

111.0

Max Length (in)

4.37

Hole Dia. (mm)

22.5

Hole Dia. (In)

0.886

Color

Grey

Thread Length (mm)

11.2

Thread Length (In)

0.44

Nut Thickness (mm)

6.4

Nut Thickness (In)

0.25

Material

Nylon 6/6 w/Buna N or TPE Sealing Gland

Flammability Rating

94V-2

Thread Type

PG
