Price List
1691
Factory Lead Time: TBD
RoHs Compliant
SHRTP-0.187-1.093Heyco White Nylon 6/6 Shorty Plug for mounting hole diameter 0.625 { SP 625 }
Hawk Electronics
Factory Lead Time: TBD
RoHs Compliant
Product Attributes
Alternate PN
SP 625
COLOR
White
Overall Height (in)
0.25
Mounting Hole Dia (in)
0.625
Head Dia (In)
0.72
Locking Step
Single
MaxPanel Thickness (mm)
1.6
MaxPanel Thickness (in)
0.062
Head Dia (mm)
18.3
Mounting Hole Dia (mm)
15.9
Overall Height (mm)
6.4
Material
Nylon 6/6
Flammability Rating
94V-2
Temperature Range
-40C to +105C
CSA
File 8919
UL
Recognized File E51579
Series Attributes
Not available at this time.
