SG3A0500BB0C

Hammond Power Solutions | sSen-G3-Cu | Electrical
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
HPS General Efficient 500 kVA with 208 - (3PH 208D, 208Y/120) Primary and and 208 - (3PH 208D or 208Y/120) Secondary Voltage Phase - Type current designs .

$30,500.00

Min: 1  Mult: 1

Product Attributes

Availability Note

This item is Build to Order and requires production time of 2-4 weeks Min.

UPC

803423127336

UNSPSC

39121001

Replaced Catalog Number

NMK500BBC

TYPE

General

Generation

current designs

Phase (Pri-Sec)

3PH Delta-Wye-N

kVA

500

Primary Voltage

208 - (3PH 208D, 208Y/120)

Secondary Voltage

208 - (3PH 208D or 208Y/120)

K Rating

None

Winding Material/Electrostatic Shield

Copper

Temperature Rise at standard 220°C Insul Class

N/A

Enclosure

N/A

Sound Level

N/A

Special Duty

Default

BIL Rating

10 kV

Enclosure Finish

ANSI 61 Grey, UL50

Frequency

60 Hz (optional 50/60 Hz available)

Impedance

Typically 1.8% to 7.5%

UL Listed

File: E112313
