Hammond Mfg. | 162-164 | PC Mount
yellow-timer-icon Factory Lead Time: 20
onlycheckmark RoHs Compliant
Transformer, low voltage PCB mount, low profile, 115/230V, 6VA, 56V C.T. @ .11A POWER TX 6VA 115/230 Hammond PN 162F56 : UPC [623980261294]

$9.50

Min: 1  Mult: 1

Product Attributes

Winding

Dual winding secondaries, non-concentrically wound

Width

1.31”

Weight (Lbs)

0.44

VA Size

6

UL Recognized

Yes

Primary

115/230V Dual

Mounting Screws

#4

Length

1.63”

Insulation

Class B Insulation - 130 C

Height

1.31”

Current

50/60 Hz

Design

Low Profile, Split bobbin

Series Photo

Click Here

CAD File

Click Here

Manufacturers Series Page

Click Here

Power Rating (Va)

6

Eccn

EAR99

Secondary (RMS) Series

56V C.T. @ .11A

Secondary (RMS) Parallel

28V @ .22A

Hammond Product Photo

Click Here

Pricing Note

Price change ~5.0% on 10/01/22

Hammond Product Type

transformer

Hammond Product Group

transformers

Hammond Series

162-164

UPC

623980261294

Lead-Time Weeks

4

Standard Stock

Yes
