Hammond Mfg. | 162 | PC Mount
yellow-timer-icon Factory Lead Time: 28
onlycheckmark RoHs Compliant
162
Hammond Transformer, low voltage PCB mount, low profile, 115/230V, 2.4VA, 56V C.T. @ .045A Part Number 162E56 [UPC 62398026128 ]

$9.00

Min: 1  Mult: 1

Product Attributes

Current

50/60 Hz

Winding

Dual winding secondaries, non-concentrically wound

Primary

115/230V Dual

Secondary (RMS) Parallel

28V @ .09A

Secondary (RMS) Series

56V C.T. @ .045A

UL Recognized

Yes

VA Size

2.4

Weight (Lbs)

0.25

Width

1.13”

Mounting Screws

N/A

Length

1.38”

Insulation

Class B Insulation - 130 C

Height

1.19”

Design

Low Profile, Split bobbin

Pricing Note

Price change ~5.0% on 10/01/22

Hammond Product Group

transformers

Hammond Product Type

transformer

Hammond Series

162-164

UPC

62398026128
