101J

Hammond Mfg. | 101 | Enclosures
green-check-icon Total Stock: 3
yellow-timer-icon Factory Lead Time: 20
onlycheckmark RoHs Compliant
101
Audio transformer, potted, primary impedance 2500 CT, secondary impedance 600 CT AUDIO TX POTTED Hammond PN 101J : UPC [623980178202]

$17.30

Min: 1  Mult: 1

Product Attributes

Mount

P.C. PIN board mount

Series Photo

Click Here

Construction

Rugged potted, completely sealed

Primary Nominal Impedance

2500 ct

Secondary Nominal Impedance

600 ct

Secondary Nominal Resistance

54

Primary Nominal Resistance

150

Manufacturers Series Page

Click Here

Eccn

EAR99

Secondary Nominal Impedance (Ohms)

600 CT

Useful Impedance Range (Ohms) Pri/Sec To Pri/Sec

1250/300 to 5000/1200

Primary Nominal Resistance (Ohms)

150

Primary Nominal Impedance (Ohms)

2500 CT

Width

0.45

Pricing Note

Price change ~5.0% on 10/01/22

Hammond Product Photo

Click Here

Length

0.45

Height

0.48

Hammond Series

101

Hammond Product Type

transformer

Hammond Product Group

transformers

Frequency range @ +20 dbm

300 Hz. to 100 Khz. +/- 0.5 db

UPC

623980178202

Frequency range @ +10 dbm

200 Hz. to 100 Khz. +/- 0.5 db

Lead-Time Weeks

4

Frequency range @ +15 dbm

200 Hz. to 100 Khz. +/- 0.5 db

Standard Stock

Yes
