101H

Hammond Mfg. | 101 | Enclosures
yellow-timer-icon Factory Lead Time: 20
onlycheckmark RoHs Compliant
101
Audio transformer, potted, primary impedance 1200 CT, secondary impedance 600 CT AUDIO TX POTTED Hammond PN 101H : UPC [623980178103]

$17.30

Min: 1  Mult: 1

Product Attributes

CAD File

Click Here

Series Photo

Click Here

Mount

P.C. PIN board mount

Construction

Rugged potted, completely sealed

Primary Nominal Impedance

1200 ct

Secondary Nominal Impedance

600 ct

Manufacturers Series Page

Click Here

Secondary Nominal Resistance

53

Primary Nominal Resistance

80

Width

0.45

Primary Nominal Impedance (Ohms)

1200 CT

Primary Nominal Resistance (Ohms)

80

Secondary Nominal Impedance (Ohms)

600 CT

Useful Impedance Range (Ohms) Pri/Sec To Pri/Sec

600/300 to 2400/120

Pricing Note

Price change ~5.0% on 10/01/22

Eccn

EAR99

Hammond Product Photo

Click Here

Height

0.48

Length

0.45

Hammond Series

101

Hammond Product Type

transformer

Hammond Product Group

transformers

Lead-Time Weeks

4

Frequency range @ +15 dbm

200 Hz. to 100 Khz. +/- 0.5 db

UPC

623980178103

Frequency range @ +20 dbm

300 Hz. to 100 Khz. +/- 0.5 db

Frequency range @ +10 dbm

200 Hz. to 100 Khz. +/- 0.5 db

Standard Stock

Yes
