Product Attributes
Tariff 301
This item is currently subject to a tariff of 15%
Product Type
Rocker
Lead Time Notes
20 - 22 Weeks
Switch Function
DPST On-None-Off
Actuator
Rocker (Flat)
Actuator Color
Black
Mounting Style Color
Snap-in, Black (22.0 Wide)
Termination
.250†Quick Connect
Actuator Marking
None
Contact Type
Silver (UL/CSA with HP Rating)
Lamp Rating
None
Series Attributes
Center Contact Material
Silver Plated, Copper Alloy
Terminal Material
Silver Plated, Copper Alloy
RoHS
Yes
Operating Temp
-20C to +85C
Non-Illuminated Actuator Material
6/6 Nylon (UL94V), black, matte finish
Mounting Type
Panel Mount, Snap-In
Insulation Resistance
10 to the 8th Ohm min.
Illuminated Actuator Material
Polycarbonate, matte finish
Housing Material
6/6 Nylon (UL94V), black, matte finish
End Contact Material
Silver Plated AgSu02In03
Electrical Life
10,000 Make-and-Break cycles at full load
Dielectric Strength
1,500 VRMS @ sea level
Contact Rating
UL/CSA – 16 AMPS @ 125 VAC, 1/8 HP; 10 AMPS @ 250 VAC, 1/3 HP
Termination Style
Quick Connect - 0.187" (4.7mm)
