E101J1A3QE2
Total Stock: 20
Factory Lead Time: 63
RoHs Compliant
SP SEALED TOGGLE SWITCH
Hawk Electronics
Total Stock: 20
Factory Lead Time: 63
RoHs Compliant
Product Attributes
Tariff 301
This item is currently subject to a tariff of 15%
Product Type
Rocker
Lead Time Notes
8 - 10 Weeks
Switch Function
SP, On-None-On
Electrical Life
40,000 make and break cycles at full load
Actuator
.531 Long Rocker
Terminations
Right Angle, snap in, PC thru-hole
Contact Material
Silver
Seal
Epoxy
Actuator Color
Black
Frame Color
No frame color required
Series Attributes
Actuator Material
Nylon, Black Standard, Internal O-ring Seal Standard with all actuators
Switch Support Material
Brass or Steel, matte-tin plated
Solderability
Per MIL-STD-202F method 208D, or EIA RS-186E method 9 (1 hour steam aging)
Operating Temp
-30C to +85C
Insulation Resistance
10 to the ninth degree Ohms per minute
Hardware Material
Nut, Screw and Lockwasher – Stainless Steel, Standoff – Nylon Standard (aluminum available by special order)
Frame Material
Spring Steel, Black Standard
Dielectric Strength
1000 Vrms min at sea level
Contact Resistance
Below 10 milli Ohms typ. Initial at 2-4 V DC, 100 mA, for both Silver and Gold plated contacts
Case Material
Glass filled nylon 6/6, flame retardant, heat stabilized (UL 94V-0).
Bushing Material
Glass filled nylon 6/6, flame retardant, heat stabilized (UL 94V-0).
Actuator Pivot Retainer
Stainless steel
Actuator Pivot Material
Nylon
Actuator Mounting Bracket
Nylon
Terminal Seal material
Epoxy
