XKD11306D

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 3A/60VDC/CTRL 3-30VDC/REMOVABLE Configured with screw Terminals and Normally Open Contacts and DIN Rail Housing with 3VDC - 30VDC @ 30mA Max . Celduc Part Number XKD11306D

$46.30

Min: 10  Mult: 10

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +90

Overall Dims (HxLxW)

(2.32 x 3.01 x 0.48)

Control voltage (nominal)

3-30VDC

Packaging Type

Carton

Load Current Max (calibre relais)

3

Protection

VDR

Housing

DIN Rail

Terminals

screw

Contact

Normally Open

Load Voltage Min

2

Load Voltage Max

60

Length-mm

76.4

Height-mm

59

Width-mm

12.2

EAN

3760283307902
