XKD10120

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 1A/200VDC/CTRL 5-30VDC Configured with screw Terminals and Normally Open Contacts and DIN Rail Housing with 5VDC - 3VDC @ 30mA Max . Celduc Part Number XKD10120

$52.60

Min: 10  Mult: 10

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +90

Overall Dims (HxLxW)

(2.09 x 3.01 x 0.48)

Control voltage (nominal)

5-30VDC

Packaging Type

Carton

Load Current Max (calibre relais)

1

Protection

VDR

Housing

DIN Rail

Terminals

screw

Contact

Normally Open

Load Voltage Min

2

Load Voltage Max

220

Length-mm

76.4

Height-mm

53

Width-mm

12.2

EAN

3760283307926

Not available at this time.
