XKA90440

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 5A/400VAC/CTRL 150-240VAC/DC Configured with screw Terminals and Normally Open Contacts and DIN Rail Housing with 150VDC - 240VDC @ 6mA Max . Celduc Part Number XKA90440

$50.50

Min: 10  Mult: 10

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +80

Overall Dims (HxLxW)

(2.09 x 3.01 x 0.68)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

150-240VAC/150-240VDC

Switching type relay

ZC

Terminals

screw

Protection

VDR

Contact

Normally Open

Housing

DIN Rail

Length-mm

76.4

Height-mm

53

Width-mm

17.2

Load continuous current (nominal)

5

EAN

3760283307933

Not available at this time.
