SU842970

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 25A/12-275VAC/VDR/INPUT 180-240VAC/LED Configured with screw Terminals and Normally Open Contacts and Screw Housing with 160VVAC/160VDC - 240VVAC/240VDC @ 6,7mA Max . Celduc Part Number SU842970

$35.40

Min: 36  Mult: 36

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(1.09 x 3.54 x 0.89)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

230VAC/230VDC

Switching type relay

ZC

Terminals

screw

Protection

VDR

Contact

Normally Open

Load Current Max (calibre relais)

25

Housing

Screw

Load Voltage Min

12

Load Voltage Max

275

Length-mm

90

Height-mm

27.7

Width-mm

22.5

Load continuous current (nominal)

25

EAN

3760283307742
