STD07205

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 2,5A/24VDC/CTRL 24VAC/DC Configured with pin Terminals and Normally Open Contacts and PCB Housing with 1215VVAC/1215VDC - 30VVAC/30VDC @ 1213mA Max . Celduc Part Number STD07205

$27.90

Min: 15  Mult: 15

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(0.82 x 1.15 x 0.51)

Control voltage (nominal)

24VAC/24VDC

Packaging Type

Tube

Load Current Max (calibre relais)

2.5

Protection

Transil

Housing

PCB

Terminals

pin

Contact

Normally Open

Load Voltage Min

0

Load Voltage Max

30

Length-mm

29.2

Height-mm

20.9

Width-mm

13

EAN

3760283308442
