STD03510

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 5A/48VDC/CTRL 24VDC Configured with pin Terminals and Normally Open Contacts and PCB Housing with 10VDC - 30VDC @ 12mA Max . Celduc Part Number STD03510

$30.10

Min: 600  Mult: 600

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(0.82 x 1.15 x 0.51)

Control voltage (nominal)

24VDC

Packaging Type

Tube

Load Current Max (calibre relais)

5

Protection

Transil

Housing

PCB

Terminals

pin

Contact

Normally Open

Load Voltage Min

0

Load Voltage Max

68

Length-mm

29.2

Height-mm

20.9

Width-mm

13

EAN

3760283308459
