SON865040

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR LOW NOISE 50A/50-480VAC/CTRL 6-32VDC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 6VDC - 32VDC @ 20mA Max . Celduc Part Number SON865040

$66.30

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-40 to +100

Overall Dims (HxLxW)

(1.18 x 2.3 x 1.77)

Packaging Type

Carton

Number of switched phases

1 phase

Terminals

screw

Switching type relay

ZC

Contact

Normally Open

Load Current Max (calibre relais)

50

Housing

Hockey Puck

Load Voltage Min

50

Load Voltage Max

480

Length-mm

58.5

Height-mm

30

Width-mm

45

EAN

3760283302679

Not available at this time.
