SOM02060

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 20A - 40 VDC - CTRL 3,5-32VDC Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 3,5VDC - 32VDC @ 35mA Max . Celduc Part Number SOM02060

$74.80

Min: 2  Mult: 2

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-25 to +90

Overall Dims (HxLxW)

(1.18 x 2.3 x 1.77)

Control voltage (nominal)

12-24VDC

Packaging Type

Carton

Load Current Max (calibre relais)

20

Protection

Transil

Housing

Hockey Puck

Terminals

screw

Contact

Normally Open

Load Voltage Min

5

Load Voltage Max

40

Length-mm

58.5

Height-mm

30

Width-mm

45

EAN

3760283302808

Not available at this time.
