SOL942960

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 25A/12-280VAC/CTRL 185-265VAC/DC/LED Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 185VAC/185VDC - 265VAC/265VDC @ 10mA Max . Celduc Part Number SOL942960

$30.00

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(0.64 x 2.28 x 1.77)

Control voltage (nominal)

230VAC/230VDC

Packaging Type

Carton

Number of switched phases

1 phase

Terminals

screw

Switching type relay

ZC

Contact

Normally Open

Load Current Max (calibre relais)

25

Housing

Hockey Puck

Load Voltage Min

12

Load Voltage Max

280

Length-mm

58

Height-mm

16.3

Width-mm

45

EAN

3760283300767

Not available at this time.
