SOL942460

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 25A/12-280VAC/CTRL 3-32VDC/LED/REGULATED INPUT Configured with screw Terminals and Normally Open Contacts and Hockey Puck Housing with 3VDC - 32VDC @ <13mA Max . Celduc Part Number SOL942460

$32.20

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(0.64 x 2.28 x 1.77)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

5-12-24VDC

Switching type relay

ZC

Load Current Max (calibre relais)

25

Housing

Hockey Puck

Terminals

screw

Contact

Normally Open

Load Voltage Min

12

Load Voltage Max

280

Length-mm

58

Height-mm

16.3

Width-mm

45

Load continuous current (nominal)

25

EAN

3760283301542
