SOD845180

Celduc | Solid State Relay
yellow-timer-icon Factory Lead Time: TBD
onlycheckmark RoHs Compliant
SSR 50A/50-265VAC/RC/CTRL 7-30VDC/LED/DIAGNOSTIC Configured with screw/spring Terminals and Normally Open Contacts and Hockey Puck Housing with 7VDC - 30VDC @ 28mA Max . Celduc Part Number SOD845180

$66.00

Min: 19  Mult: 19

Product Attributes


Click Here

Manufacturers direct Page

Click Here

Temperature Range

-55 to +100

Overall Dims (HxLxW)

(1.32 x 2.34 x 1.76)

Packaging Type

Carton

Number of switched phases

1 phase

Control voltage (nominal)

12-24VDC

Switching type relay

ZC

Terminals

screw/spring

Protection

RC

Contact

Normally Open

Load Current Max (calibre relais)

60

Housing

Hockey Puck

Load Voltage Min

50

Load Voltage Max

265

Length-mm

59.4

Height-mm

33.5

Width-mm

44.8

Load continuous current (nominal)

50

EAN

3760283300958
